POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 1068

Connection manual (Function)

Page of 1173

/ 1173

EDIT

DATE DISIGNE

DESCRIPTION

TITLE

DRAW

FANUC Power Mate i -MODEL D/H

Enhancement of External I/O device

control function

B-63173EN/01-32

SHEET

14/40

APPROV.

FANUC LTD

Format of diagnosis data

N Data number

P Data ;

N: Give data number by a value after N as follows

・In case the parameter No.8761#0(EIB)=0 (the former way)

(when Data input/output via I/O Link is selected)

Data number=Diagnosis number+20000

・In case the parameter No.8761#0(EIB)=1 (the enhanced way)

(when Data input/output via I/O Link is not selected)

Data number=Diagnosis numeber

P: Give data by a value followed after P

When diagnosis number is not defined, data number followed after

N is output and data followed after P.is not output.

When diagnosis data is axis type, the format is as follows.

N Data number

A1 P Data A2 P Data ..... ;

A: Give data number by a value followed by A only in case of axis

type diagnosis data.

A1: the first axis, A2: the second axis, .......

The header “(DGN)” is output at the top of the file in order to show this

data is diagnosis data.

Ex)

% ;

(DGN) ;

......

N00040 P 00000001 ;

N00041 P 0 ;

......
