POWER MATE i-MODEL D/H (FUNCTION) Connection manual (Function) Page 413

Connection manual (Function)

Page of 1173

/ 1173

B–63173EN–1/01

9. SPINDLE SPEED FUNCTION

400

4044 Proportional gain of the velocity loop in servo mode (gear 1, gear 2)

4045 Proportional gain of the velocity loop in servo mode (gear 3)

[Unit of data]

[Valid data range] 0 to 32767

Set a proportional gain for the velocity loop in a servo mode (such as rigid

tapping mode).

4052 Integral gain of the velocity loop in the servo mode (gear 1, gear 2)

4053 Integral gain of the velocity loop in the servo mode(gear 3)

[Unit of data]

[Valid data range] 0 to 32767

Set an integral gain of the velocity loop in a servo mode (such as rigid

tapping mode).

4065 Position gain in the servo mode (HIGH) (CFPGH)

4066 Position gain in the servo mode (MEDIUM HIGH) (CFPGMH)

4067 Position gain in the servo mode (MEDIUM LOW) (CFPGML)

4068 Position gain in the servo mode (LOW) (CFPGL)

[Unit of data] 0.01 sec

–1

[Valid data range] 0 to 65535

Set a servo loop gain in a servo mode (such as rigid tapping mode).
