Series 16i Additional Manual Page 16

Additional Manual
16
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
X
Y
Z
N3
N4
N6
N5
N7
N8
N10
N9
Fig.2.14 Conceptual Diagram
Y
Z
VaVb
46°45°
Va: Tool direction vector when A = -46
Vb: Tool direction vector when A=45
A
: End point of N3
B: End point of N4
C: End point of N6
A
B
C
Fig.2.15 Tool Direction Vector
e3
e2
A
’C’B’
V1
V2
A
’ : Point A projected onto the compensation plane
B’ : Point B projected onto the compensation plane
C’ : Point C projected onto the compensation plane
Fig.2.16 Compensation Vector at the End Point (Point B) of N4 (on
Compensation Plane)
