Series 16i Additional Manual Page 40

Additional Manual
40
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
・Parameter example
On the machine shown in Fig.4.1 parameters must be specified as follows:
The axis numbers are assumed as follows: X = 1, Y = 2, Z = 3, A = 4, B = 5
Parameter
No.
Setting
(IS-B)
Description
19720 1 (X) Axis number of linear axis 1
19721 2 (Y) Axis number of linear axis 2
19722 3 (Z) Axis number of linear axis 3
19723 - 5 (B) Axis number of rotary axis (first set)
19724 2 (Y) Axis number of the linear axis corresponding to the rotary
axis (first set)
19725 - 4 (A) Axis number of rotary axis (second set)
19726 1 (X) Axis number of the linear axis corresponding to the rotary
axis (second set)
19730 0 Reference angle for the rotary axis (first set)
19731 0 Reference angle for the rotary axis (second set)
