Series 16i Additional Manual Page 66

Additional Manual
66
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
19615 Rotary axis used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (second set)
19616 Linear axis 1 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (second set)
19617 Linear axis 2 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (second set)
19618 Linear axis 3 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (second set)
[Data type] Byte
[Valid data range] 0 ~ number of controlled axes
Set the rotary axis and the linear axes used to execute three-dimensional cutter
compensation and tool radius compensation for 5-axis machining (second set).
19619 Angle of rotary axis used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (second set)
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 ~ +99999999
Set the angle of the rotary axis used to execute three-dimensional cutter
compensation and tool radius compensation for 5-axis machining (second set).
Parameters No.. 19610 to 19619
First set Second set
Rotary axis 19610 19615
Linear axis 1 19611 19616
Linear axis 2 19612 19617
Linear axis 3 19613 19618
Angle 19614 19619
- Set the relationship between the rotary axis and the rotary plane.
- The relationship may be set for each of two sets. This enables setup of a
machine controlled with two rotary axes.
- The tool direction of the rotary axis of the first set is calculated first. Then, using
the result of the calculation, the tool direction of the rotary axis of the second is
calculated.
- If two rotary axes are used and the rotation of the other rotary axis causes the
rotary plane to vary, set the rotary plane assumed when the position of the rotary
axis is at 0 degrees.
- If only one rotary axis is used, set 0 for the rotary axis of the second set.
- Generally, the direction vector of a rotary axis has components in three directions.
This function supports vectors with components in a single direction and those
with components in two directions. See the following for details:
