Series 16i Additional Manual Page 60

Additional Manual
60
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
Parameter
No.
Setting
value
(IS-B)
Description
19607#4 1 Intersection offset for Mixed-type machine is used
19680 21 Mechanical unit type
19681 5 (B) Controlled-axis number for the first rotation axis
19682 2 (Y) Axis direction of the first rotation axis
19683 0 Inclination angle when the first rotation axis is an inclined axis
19684 0 Rotation direction of the first rotation axis
19685 0 Rotation angle when the first rotation axis is a hypothetical axis
19686 5 (B) Controlled-axis number for the second rotation axis
19687 2 (Y) Axis direction of the second rotation axis
19688 0 Inclination angle when the second rotation axis is inclined
19689 0 Rotation direction of the second rotation axis
19690 0 Rotation angle when the second rotation axis is a hypothetical axis
19696#0 0 The first rotary axis is an ordinary rotary axis.
19696#1 0 The second rotary axis is an ordinary rotary axis.
19697 3 Reference tool axis direction
19700 5000 Rotary table position (X-axis of the basic three axes)
19701 2000 Rotary table position (Y-axis of the basic three axes)
19702 -15000 Rotary table position (Z-axis of the basic three axes)
19703 0 Intersection offset vector between the first and second rotation axes of the table
19704 0 Intersection offset vector between the first and second rotation axes of the table
19705 0 Intersection offset vector between the first and second rotation axes of the table
19709 3000 Intersection offset vector between the tool axis and tool rotation axis
19710 0 Intersection offset vector between the tool axis and tool rotation axis
19711 2000 Intersection offset vector between the tool axis and tool rotation axis
19712 0 Intersection offset vector between the second and first rotation axes of the tool
19713 0 Intersection offset vector between the second and first rotation axes of the tool
19714 0 Intersection offset vector between the second and first rotation axes of the tool
19666 2000 Tool holder offset value
NOTE
If the intersection offset for mixed-type machine is valid (parameter No.
19607#4 is set to1), the following parameters should be set to “0”.
No.19610∼19623, No.19720∼19726,19730,19731,19734
5)
