FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
No. Message Description
P/S5409 ILLEGAL PARAMETER IN G41.3
The parameter settings (parameter Nos. 19610 to 19619)
for determining the relationship between the axis of
rotation and the rotary plane are incorrect.
P/S5460 ILLEGAL USE OF G41.4/G42.4
(1) Any of the parameters No.19720 to 19726, related to
the tool radius compensation for 5-axis machining, is
not correct.
(2) At the start of the rotary table support of cutter
compensation (G41.4/G42.4), axes other than those
specified for parameters No.19720 to 19722 were
selected as a plane.
(3) In the mode of the tool radius compensation for 5-axis
machining (G41.4/G42.4), a move command other
than G00/G01 (such as G02) was issued.
P/S5461 ILLEGAL USE OF G41.5/G42.5
(1) The parameters (No.19720 to No.19726) related to
tool radius compensation for 5-axis machining are not
specified properly.
(2) An attempt was made to issue the G39 command in
the mode of three-dimensional tool radius
compensation for 5-axis machining (G41.5/G42.5).
(3) An attempt was made to issue a move command
other than G00 and G01, such as G02, at the startup
of three-dimensional tool radius compensation for
5-axis machining (G41.5/G42.5).
P/S5459 ILLEGAL PARAMETER OF MACHINE
COMPONENT
A parameter (No.19680 to No.19714) for configuring the
machine is incorrect.
