Series 16i Additional Manual Page 85

Additional Manual
85
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
19720 Axis number of linear axis 1 in the tool radius compensation for 5-axis machining
19721 Axis number of linear axis 2 in the tool radius compensation for 5-axis machining
19722 Axis number of linear axis 3 in the tool radius compensation for 5-axis machining
[Data type] Byte
[Valid data range] 1 ~ number of controlled axes
Set the axis numbers of the three linear axes used for the tool radius compensation
for 5-axis machining.
(The linear axes correspond to the coordinate axes in the workpiece coordinate
system.)
NOTE
As for this parameter, input is necessary only for rotary table axes
4)
