Series 16i Additional Manual Page 86

Additional Manual
86
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
10.5 Parameters related to G-code unification
#7 #6 #5 #4 #3 #2 #1 #0
19607 CGR
[Data type] Bit
# 0 CGR In the machine which contains a table rotation axis, when the tool radius
compensation for 5-axis machining is done, the commanded G-code
0: Uses G41.4 or G42.4 with the rotary table type machine, and G41.5 or G42.5
with the mix-type machine.
1: Uses G41.2 or G42.2 without relations in the type of the machine.
NOTE
When this parameter is set, the power must be turned off before
operation
is continued.
4)
