Series 16i Additional Manual Page 3

Additional Manual
3
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
1. General
For machines having multiple rotation axes for freely controlling the orientation of a
tool axis, this function calculates a tool vector from the positions of these rotation
axes. The function then calculates a compensation vector in a plane (compensation
plane) perpendicular to the tool vector and performs cutter compensation for 5-axis
machining.
This function is applicable to the following machine configurations. (See Fig.1.1.)
<1> Tool rotation type machine controlled with two rotary tool axes
<2> Table rotation type machine controlled with two rotary table axes
<3> Mixed-type machine controlled with one rotary tool axis and one rotary axis
<2> Table rotation type
machine
<1> Tool rotation
type machine
X
C
B
Z
Y
A
C
X
Z
Y
