Series 16i Additional Manual Page 35

Additional Manual
35
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
Parameter
No.
Setting
value
(IS-B)
Description
19607#4 1 Intersection offset for tool rotation type machine is used
19680 2 Mechanical unit type
19681 6 (C) Controlled-axis number for the first rotation axis
19682 3 (Z) Axis direction of the first rotation axis
19683 0 Inclination angle when the first rotation axis is an inclined axis
19684 0 Rotation direction of the first rotation axis
19685 0 Rotation angle when the first rotation axis is a hypothetical axis
19686 5 (B) Controlled-axis number for the second rotation axis
19687 2 (Y) Axis direction of the second rotation axis
19688 0 Inclination angle when the second rotation axis is inclined
19689 0 Rotation direction of the second rotation axis
19690 0 Rotation angle when the second rotation axis is a hypothetical axis
19696#0 0 The first rotary axis is an ordinary rotary axis.
19696#1 0 The second rotary axis is an ordinary rotary axis.
19697 3 Reference tool axis direction
19700 0 Rotary table position (X-axis of the basic three axes)
19701 0 Rotary table position (Y-axis of the basic three axes)
19702 0 Rotary table position (Z-axis of the basic three axes)
19703 0 Intersection offset vector between the first and second rotation axes of the table
19704 0 Intersection offset vector between the first and second rotation axes of the table
19705 0 Intersection offset vector between the first and second rotation axes of the table
19709 5000 Intersection offset vector between the tool axis and tool rotation axis
19710 0 Intersection offset vector between the tool axis and tool rotation axis
19711 3000 Intersection offset vector between the tool axis and tool rotation axis
19712 3000 Intersection offset vector between the second and first rotation axes of the tool
19713 3000 Intersection offset vector between the second and first rotation axes of the tool
19714 8000 Intersection offset vector between the second and first rotation axes of the tool
19666 2000 Tool holder offset value
NOTE
If the intersection offset for tool rotation type machine is valid (parameter
No. 19607#4 is set to1), the following parameters should be set to “0”.
No.19610∼19623, No.19700∼19705, No.19720∼19726,19730,19731,19734
5)
