FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
19620 Reference angle of rotary axis used to execute three-dimensional cutter
compensation (first set)
19621 Reference angle of rotary axis used to execute three-dimensional cutter
compensation (second set)
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 ~ +99999999
Set the reference angles of the rotary axes used to execute three-dimensional tool
compensation and tool radius compensation for 5-axis machining.
Set the angles of the rotary axes assumed when the tool direction (parameters
No.19622 to 19623).
Usually, set a value of 0.0.
19622 Reference angle of tool axis of plane of liner axes 2 and 3 (RA)
19623 Reference angle of tool axis of plane of liner axes 3 and 1 (RB)
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 ~ +99999999
Set the two angles RA and RB to specify the direction of the three-dimensional cutter
compensation and tool axis used to execute the tool radius compensation for 5-axis
machining.
Parameters No.19622 and 19623
As the directions of compensation vectors, using the direction of linear axis 3
(parameter No.19613) as a reference, set the rotary angles (R
A
and R
B
) from that
reference.
R
A
: Rotation in the plus direction is rotation from the plus direction of linear axis 2
to the plus direction of linear axis 3, assuming that the rotation is on the plane of
linear axes 2 and 3.
R
B
: Rotation in the plus direction is rotation from the plus direction of linear axis 3
to the plus direction of linear axis 1, assuming that the rotation is on the plane of
linear axes 3 and 1.
Linear axes 1, 2, and 3 are those axes that have been specified with parameters
No.19611 to 19613.
