FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
19680 Type of a mechanical unit
[Data type] Byte
[Valid data range] 0 ~ 21
Specify the type of a mechanical unit.
PRM19680
Mechanical unit
type
Controlled rotation
axis
Master and slave
0
Mechanism having no
rotation axis
2
Tool rotation
type
Two rotation axes of
the tool
The first rotation axis is the master,
and the second rotation axis is the
slave.
12
Table rotation
type
Two rotation axes of
the table
The first rotation axis is the master,
and the second rotation axis is the
slave.
21 Mixed type
One rotation axis of the
tool
＋ one rotation
axis of the table
The first rotation axis is the tool
rotation axis, and the second
rotation axis is the table rotation
axis.
NOTE
Count also hypothetical axis as a rotary axis to be controlled
<About the hypothetical axis>
In some cases, it is convenient to use an imaginary rotary axis whose
angle is fixed at a certain value.
An example of these cases might be a case in which a tool is
mounted through an attachment in a slanted manner.
In this case, the imaginary axis is the hypothetical axis.
Parameter No.19696#0,#1 specify whether the corresponding axes
are ordinary or hypothetical axes.
5)
4)
4)
