Series 16i Additional Manual Page 65

Additional Manual
65
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
10. Parameters
10.1 About the machine configuration
・First set and Second set
If there are two rotary axes for controlling the orientation of a tool or two rotary axes
for controlling the orientation of a table, a typical structure is such that a rotary
mechanism is on the tip of another rotary mechanism. At this time, the rotary axis of
the former is called the second set (master axis), and the front rotary axis is called
first set (slave axis).
10.2 Parameters related to rotary tool axis
19610 Rotary axis 1 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (first set)
19611 Linear axis 1 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (first set)
19612 Linear axis 2 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (first set)
19613 Linear axis 3 used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (first set)
[Data type] Byte
[Valid data range] 0 ~ number of controlled axes
Set the rotary axis and the linear axes used to execute three-dimensional cutter
compensation and tool radius compensation for 5-axis machining (first set).
19614 Angle of rotary axis used to execute three-dimensional cutter compensation
and tool radius compensation for 5-axis machining (first set)
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 ~ +99999999
Set the angle of the rotary axis used to execute three-dimensional cutter
compensation and tool radius compensation for 5-axis machining (first set).
