FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
11. Alarm and message
No. Message Description
P/S33 CRC:NO INTERSECTION
There is not point of intersection of the compensated tool
center path during cutter compensation.
P/S37 CRC:PLANE CHANGE
An attempt was made to change the plane in the cutter
compensation mode.
To change the plane, cancel the cutter compensation
mode.
P/S41 CRC:INTERFERENCE
The depth of the cut is too great during cutter
compensation. Check the program.
The criteria for judging interference are as follows:
(1) The direction of movement of the programmed block
differs from the direction of movement of the
corresponding tool center path block by 90° or more or
270° or less.
The check in this case can be disabled by setting CNC
parameter No. 6001#1 to "1".
(2) In the case of an arc, the difference in angle between
the start and end points of the programmed block differs
by 180° or more with the difference in angle between the
start and end points of the corresponding tool center path
block.
P/S5000 ILLEGAL COMMAND CODE (HPCC)
An invalid command (G code etc.) was specified in HPCC
mode.
P/S5196 ILLEGAL AXIS OPERATION
A function which cannot be used during HPCC function or
5-axis control function is being executed was commanded.
P/S5405 ILLEGAL PARAMETER IN
G41.2/G42.2
The parameter settings (parameter Nos. 19610 to 19619)
for determining the relationship between the axis of rotation
and the rotary plane are incorrect.
P/S5406 G41.3/G40 FORMAT ERROR
(1) A move instruction was specified in a block in which the
G41.3 or G40 code is specified.
(2) A G or M code which suppresses buffering was
specified in the block in which the G41.3 code was
specified.
P/S5407 ILLEGAL COMMAND IN G41.3
(1) A G code other than G00 or G01 in group 01 was
specified in the G41.3 mode.
(2) An offset (G code in group 07) was specified in the
G41.3 mode.
(3) The block following the block in which G41.3 (startup)
was specified did not contain a move command.
P/S5408 G41.3 ILLEGAL START_UP
(1) The G41.3 G code (startup) was specified in a group 01
mode for other than G00 and G01.
(2) The angle formed by the tool direction vector and the
movement direction vector was 0° or 180° degrees at
startup.
