Series 16i Additional Manual Page 74

Additional Manual
74
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
#7 #6 #5 #4 #3 #2 #1 #0
19607 RTI
[Data type] Bit
# 4 RTI The intersection offset for tool rotation type ,rotary table type, mixed-type machine of
tool radius compensation for 5-axis machining should be
0: invalid.
1: valid.
19666 Tool holder offset value
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C unit
Millimeter machine 0.001 0.0001 mm
Inch machine 0.0001 0.00001 inch
[Valid data range] -99999999 ~ +99999999
When tool length compensation in tool axis direction function, tool tip center rotation
handle feed, the display of the tool center point position, tool center point control, tool
center point control for 5-axis machining, tool radius compensation for 5-axis
machining and tilted working plane command mode (after G53.1) are performed,
specify the offset for the machine-specific section from the rotation center of the
rotation axis to the tool mounting position (the tool holder offset value) in tool length
compensation. For the tool length compensation function, the holder offset function
can be enabled by setting bit 7 (ETH) of parameter No.19665.
