Series 16i Additional Manual Page 5

Additional Manual
5
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
2. Tool radius compensation for tool rotation type machine
General
In a 5-axis machine having two tool rotation axes as shown in the figure below, this
function can perform cutter compensation.
Shown below is a 5-axis machine that has tool rotation axis B on the Y-axis and tool
rotation axis C on the Z-axis.
This machine configuration is used as a sample configuration in the following
explanation unless otherwise noted.
Cutter compensation in tool rotation machines is classified into two types according
to the way of machining: tool side offset and leading edge offset.
Work coordinate system: A coordinate system
used for creating programs
B
C
Z
Y
X
X
Y
Z
Work coordinate s
y
stem
Fig.2.1
