Series 16i Additional Manual Page 7

Additional Manual
7
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
Description
・Operation at compensation start-up and cancellation
(1) Type A
The tool is moved in the same way as for cutter compensation as shown below.
Tool
G41.2
G40
:
Tool center path
:Programmed tool path
Operation in linear interpolation
:Tool center path
:
Programmed tool path
Tool
G42.2
G40
Operation in circular interpolation
Fig.2.3 Operation at compensation start-up and cancellation
(Type A)
(2) Type B
The tool is moved in the same way as for cutter compensation as shown below.
Tool
G41.2
G40
:Tool center path
:Programmed tool path
Operation in linear interpolation
