Series 16i Additional Manual Page 50

Additional Manual
50
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
Parameter
No.
Setting
value
(IS-B)
Description
19607#4 1 Intersection offset for rotary table type machine is used
19720 1 (X) Axis number of linear axis 1 (first axis of the workpiece coordinate system)
19721 2 (Y) Axis number of linear axis 2 (second axis of the workpiece coordinate system)
19722 3 (Z) Axis number of linear axis 3 (third axis of the workpiece coordinate system)
19680 12 Mechanical unit type
19681 5 (B) Controlled axis number for the first rotary axis
19682 5 Axis direction for the first rotary axis
19683 -45000 Angle of the first rotary axis
19684 1 Rotation direction of the first rotary axis
19685 0 Rotation angle for the first rotary axis when it is a hypothetical axis
19686 6 (C) Controlled axis number for the second rotary axis
19687 3 (Z) Axis direction for the second rotary axis
19688 0 Angle of the second rotary axis
19689 1 Rotation direction of the second rotary axis
19690 0 Rotation angle for the second rotary axis when it is a hypothetical axis
19696#0 0 The first rotary axis is an ordinary rotary axis.
19696#1 0 The second rotary axis is an ordinary rotary axis.
19697 3 Tool axis direction
19700 0 Rotary table position (X-axis)
19701 500000 Rotary table position (Y-axis)
19702 0 Rotary table position (Z-axis)
19703 100000 Intersection offset vector between the first and second rotary axes of the table (X-axis)
19704 -100000 Intersection offset vector between the first and second rotary axes of the table (Y-axis)
19705 100000 Intersection offset vector between the first and second rotary axes of the table (Z-axis)
NOTE
1. If the intersection offset for rotary table type machine is valid
(parameter No. 19607#4 is set to1), the following parameters should be
set to “0”.
No.19610∼19623, No.19723∼19726,19730,19731,19734
2. In case of the machine with inclined rotary axes, “Inclined rotary axis
control” option is necessary in order to use “tool radius compensation
for 5 axis machining” function.
