Series 16i Additional Manual Page 78

Additional Manual
78
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
19685 Rotation angle when the first rotary axis is a hypothetical axis
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 ~ +99999999
When the first rotation axis is a hypothetical axis (bit 0 (IA1) of parameter No. 19696
is 1), set the rotation angle.
19686 Controlled axis number for the second rotary axis
[Data type] Byte
[Valid data range] 0 ~ number of controlled axes
Specify the controlled axis number for the second rotary axis.
For a hypothetical axis (bit 1 (IA2) of parameter No. 19696 is 1), set 0.
19687 Axis direction for the second rotary axis
[Data type] Byte
[Valid data range] 0 to 6
Specify the axis direction of the second rotation axis.
1: On X-axis
2: On Y-axis
3: On Z-axis
4: On an axis tilted a certain angle from the positive X-axis to positive Y-axis
5: On an axis tilted a certain angle from the positive Y-axis to positive Z-axis
6: On an axis tilted a certain angle from the positive Z-axis to positive X-axis
(A value 4 to 6 is to be set when the inclined rotation axis control function is used.)
The direction when the master axis is at 0 degrees must be set.
19688 Angular angle when the second rotary axis is a angular axis
[Data type] 2 Word
[Unit of data]
increment system IS-B IS-C Unit
Data unit 0.001 0.0001 deg
[Valid data range] -99999999 ~ +99999999
If parameter No. 19687 is set to a value 1 to 3, set 0 degrees.
If parameter No. 19687 is set to a value 4 to 6, set the inclination angle.
4)
