Series 16i Additional Manual Page 41

Additional Manual
41
/
88
A-78710E
Edit
Apprv. Desig.
Sheet
Title
Draw
No.
Date
Design
Descri
p
tion
Date
FANUC Series 16i –MB, 18i –MB5
Tool Radius Compensation For 5-Axis
machining Specifications
Dec.01.2001
02 Mar.22.2002
T.Mochia All revision
H.Kouzai
Sheet
T.Mochida H.Kouzai
03 Mar.28.2003
MTanaka All revision H.kouzai
04 Aug.05.2003
T.Horie Intersection offset, G-code unification add. H.kouzai
05 Jun.02.2004 Intersection offset(tool rotation type, Mixed type)
5. Intersection offset for rotary table type machine
General
When parameter No.19607#4 is set to 1, tool radius compensation for 5 axis
machining can be applied to the rotary table type machine whose two rotary axes
don't intersected.(See.Fig5.1)
B
A
Z
X
Y
X
Y
Z
Workpiece coordinate system
This machine is trunnion type that has table rotation axis
A
(master) on the X-axis and table rotation axis B (slave) on
the Y-axis.
Programs are created in the workpiece coordinate system.
Table coordinate
system
shows the direction of the machine movement
Fig.5.1 Machine with two rotary table axes which don't intersect
4)
