  2. FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator

FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 25

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ‘05.04.20 N.Sonoda Newly designed Sheet 025
Edit Date Design Description
/ 064
CROF At emergency stop, current offset is
1 : re-taken in.
0 : not re-taken in. (standard)
GOKAN When the velocity loop proportional high-speed processing is applied,
1 : servo characteristic is compatible with 90B3 series
0 : servo characteristic is compatible with 90D0 series
(Note) It is called Compatible bit parameter.
TCAVE Average torque is
1 : outputted (Note) You must set 1 for No.2208#7 at same time.
0 : not outputted
HRV3AL
1 : Always enabling high-speed HRV current control without G05.4
NOG54 High-speed HRV current control is
1 : executed with G01
0 : executed with both G01 and G05.4
Note
Normally Acceleration feedback function is unavailable when Velocity loop proportional
high-speed processing function is valid. But it is available if Compatible bit (No.2227#2) is set to
1. Acceleration feedback function is kept compatible with 90B3 series by this bit.
2201
CROF
RUNLVL
2228
SYSLRN
HSBLC
FRQ
2229
ABSEN
RCNEG
TIMADJ STPREDTAWAMI
2271
HRV3AL
TCAVE
2227
PARTLEGOKAN ERRCHKANGLNG
SNGREF
2283
NOG54
2066
K2AUX Acceleration feedback gain (negative value)
