7.2.4 How to transmit Learning Data
To SAVE Learning Data (Servo → HD)
1) All of the first, you must confirm the error of Learning control converged well.
2) Set No.2511 of Profile number to zero in case of the lump deal method.
Check No.2510 of Total Profile number beforehand.
Note) You can SAVE Learning Data every the profile data, which is called the partial deal method.
(The transmitted area of Learning Data is the shade of Fig.7.1.)
The lump deal method: No.2511=0 ;Saving all Learning data of an axis.
The partial deal method : No.2511= Profile number ;Saving the specified Learning Data.
3) Set CNC to EDIT mode and then you can transmit it to HD on PC using your application software. Blinking
"RESET" denotes busy state on transmit.
Note
1) You can't change parameter or run with parts program simultaneously with this function.
2) The format of Learning Data is not disclosed which is the binary data. Don't edit it, otherwise
there might be possibility not to transmit well.
3) It takes about 18 seconds for transmission from Servo to CNC in case of the lump deal method.
Profile No 1
Profile No 2
Profile No 3
….
Learning Memory
Profile No 1
Profile No 2
Profile No 3
….
Learning Memory
Lump deal method
Partial deal method
SAVE
(Read)
Hard Disk
Learning Data
file
Fig 7.1 To SAVE Learning Data by two ways of
the Lump deal method (No.2510=0) and the Partial deal method (No2510=2)
