FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 56

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ’05.04.20 N.Sonoda Newly designed Sheet 056
Edit Date Design Description / 064
Appendix 3. Parameter table for Learning control
Standard Parameter for Learning Control for Piston (1/4)
(Note 1) You need to set the Learning parameter value because of not auto-Loading.
(Note 2) These are parameters for Piston Lathe or Lead cutting machine.
You need the auto-loading by the Motor No.74 for αL9.
(Note3) After you did the auto-loading by the Motor No.285 for αis8, set the following parameters.
No.2017#7=1, No.2227#2=1
No.2040= standard*1.5, No.2041=standard*1.5, No.2043= standard/2
Velocity gain 700%
Motor type
αL9
α
L9
α
L9 αis8/4000
Motor spec. 0564 0564 0564 0235
Motor ID 74 74 (74) (285)
Velocity 0.5ms(HS) 0.5ms(HS) 250us(HS) 0.5ms(HS)
Remarks Piston Lead Cam Piston Piston
Amplifiler 80Ap (re) 80Ap (re) 80Ap #H 80Ap
Pg No.1825 18000 18000 18000 18000
PI No.2003
00001000 00001000 00001001 00001000
Interrupt No.2004
11110001 11110001 11111010 00100001
High speed No.2005
xxx0xxxx xxx0xxxx xxx0xxxx xxx0xxxx
func. bits No.2007
xxxxxxx0 xxxxxxx0 xxxxxxx0 xxxxxxx0
HS Veloc. No.2017
1xxxxxxx 1xxxxxxx 1xxxxxxx 1xxxxxxx
Learning
No.2019
x1xxxxxx x1xxxxxxx x1xxxxxxx x1xxxxxxx
HRV3 No.2013
xxxxxxx0 xxxxxxx0 xxxxxxx0 xxxxxxx0
Compatible No.2227
xxxxx1xx xxxxx1xx xxxxx1xx xxxxx1xx
PK1 No.2040 1527 1527 1828 825
PK2 No.2041 -5069 -5069 -8109 -5173
PK3 No.2042 -2691 -2691 -2028 -1307
PK1V No.2043 25 25 22 17
PK2V No.2044 -1852 -1852 -2215 -294
PK4V No.2046 -24708 -24708 -24708 -8235
PPMAX No.2053 21 21 21 21
PDDP No.2054 0 0 0 1894
PHYST No.2055 82 82 82 319
TRQLIM No.2060 6918 6918 6918 7282
POVC1 No.2062 32614 32614 32614 32609
POVC2 No.2063 1925 1925 1925 1993
POVCLM No.2065 5716 5716 5716 5920
RTCURR No.2086 1760 1760 1760 1253
MGSTCM No.2110 0 0 0 519
FBND
No.2512
500 300 700 500
GODMX
No.2526
5675
GODMN
No.2527
3503
GCOEF
No.2528
64 64 64 64
EXGX K2
No.2529
-32 -32 -32 -32
EXGX K3
No.2530
0000
EXGX K4
No.2531
0000
EXGX K5
No.2532
0000
EXGX K6
No.2533
0000
