Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ‘05.04.20 N.Sonoda Newly designed Sheet 030
Edit Date Design Description
/ 064
cycle.
Servo software judges the final cycle by the Learning count (No.2516, No.2518, or etc).
Data range : 0 to 700 stepping up every 50 (When Velocity 0.5msec)
0 to 350 stepping up every 25 (When Velocity 1msec)
Standard : Refer to Appendix 3. Parameter table for Learning control.
FBND decides the band-width of Learning controller, so the higher is the better as far as being stable.
The maximum value in the range where there is no vibration is set. Be careful, if the command by user
includes the high frequency spectrum exceeds FBND, the error of the frequency spectrum does not
converge.
(Note) If you set 0, Learning control isn’t performed. You can disable Learning control without power off.
Data range : 0 to 20
Standard : Refer to Appendix 3. Parameter table for Learning control.
Data range : 0 to GODMX
Standard : Refer to Appendix 3. Parameter table for Learning control.
(Note) In case of Expanded Gx being enable (No.2443#3 = 1), set GXDMN to 0.
Data range : 0 to 128
Standard : 64 (When No.2443#3 = 0)
(Note) In case of Expanded Gx being enable (No.2443#3 = 1), Refer to
Appendix 3. Parameter table for Learning control.
2512
FBND Frequency band of low pass filter [Hz]
2526
GODMX Maximum order of Gx
2527
GODMN Minimum order of Gx
2528
GCOEF / EXGXK1 Coefficient of Gx / Coefficient 1 of expanded Gx
