FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 27

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ‘05.04.20 N.Sonoda Newly designed Sheet 027
Edit Date Design Description
/ 064
6. Learning Control function
6.1 Learning Control parameters
SLEN Learning control (Option) is
1 : Available.
0 : Not available.
ICM Compensation data mode is
1 : Available.
0 : Not available.
LCON Learning control is
1 : Suspension mode.
0 : Continuation mode.
EXGX Dynamic characteristic compensation (Gx) is
1 : Expanded Gx.
0 : Normal Gx. (standard)
(Note) Expanded Gx makes the compensation of high precision. According to Gx setting, refer to
Appendix 3. Parameter table for Learning Control.
UNTSL The unit of command period (No.2517, No.2519, etc) and Learning starting time
(No.2514) and Shock reducing counter (No.2542) is
1 : data number. ( command period (msec) / Velocity period (msec) )
0 : msec. (standard)
(Example) When UNTSL = 1, you must set No.2542 to 125 in case that Command period is 62.5msec and
Velocity loop is 1msec.
MEMCLR At G05 finish, Learning memory is
1 : clear in .
0 : clear in ICM=1 (compensation mode), not clear in ICM=0. (standard)
(Note) After Learning memory clear, this bit is set to 0. (cf. 7.1.2 Processing flow)
PRFCLR In case of ICM=1 (Compensation mode),
1 : Learning memory specified by profile number (No.2511) is anytime cleared out.
0 : Learning memory is not cleared out.
(Note) After Learning memory clear, this bit is reset to 0. (cf. 7.1.2 Processing flow)
QUCKST Learning control is executed
1 : at High-speed cutting (G05)
0 : at High-speed cutting (G05) and not zero command
ICM LCON Learning Mode
0 0 Suspension
0 1 Continuation
1 0 Compensation data suspension
1 1 Compensation data continuation
2443
LSTP
MSCHK
EXGXLCONICM
2442
TRASMT
ADAPTUNTSLADERSLSTPRED
VCMDCL
2226
QUCKST
SVGDCG FFEXPLCT2WD
PRFCLRMEMCL
2019
LEBFEX
TANDECINSYS
SLENDPFBCT
SUPRSY
