  2. FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator

FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 63

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ‘05.04.20 N.Sonoda Newly designed Sheet 063
Edit Date Design Description / 064
1. Difference of velocity loop characteristic between 90D3 series and 90B3 series
There are the difference between 90D3 and 90B3 in the characteristic of velocity loop as follows.
In 90D3 series, PK1V (No.2043) and PK4V (No.2046) are calculated automatically according to velocity
sampling period.
Furthermore there are the following difference in Velocity loop high-speed proportional processing
function (No.2017#7=1).
• 300Hz torque command filter becomes valid regardless of No.2067=0.
• Torque command filter (No.2067) is calculated automatically according to velocity sampling period.
• Acceleration feedback function (No.2066 < 0) is unavailable.
If you change over servo parameters from series 16
i to series 30i, set compatible bit (No.2227#2) to 1.
In the detail parameter, refer to “
5.1.4 Caution in case of servo parameter setting” and “Appendix
6. Parameter number difference between series 16
i and 30i”.
2. The setting for motor ID No.74 (
αL9) or No.75 (αL6)
If you use the parameter set for motor ID No.74 or No.75 on series 16
i and transfer it to series 30i, refer
to “Standard parameters for Learning control (1/4) in
“Appendix 3. Parameter table for Learning
control
”. Please modify the following parameters at an emergency stop.
Take care because the parameter No.2007, No.2008, N0.2230-No.2266 were changed at series 30
i.
No.2005#4=1 -> 0 (High speed axis)
No.2007#0=1 -> 0
No.2017#7=0 -> 1 (Velocity loop high-speed proportional processing function)
No.2227#2=0 -> 1 (Compatible bit)
No.2066 and No.2067 leave the same value.
3. The setting for Learning HRV2 control (HRV2 control + Velocity 0.5msec.)
If you use Learning HRV2 control on series 16
i and transfer it to series 30i, refer to “Standard parameters
for Learning control (3/4) in
“Appendix 3. Parameter table for Learning control”.
Take care because the parameter No.2007, No.2008, N0.2230-No.2266 were changed at series 30
i.
No.2227#2=0 -> 1 (Compatible bit)
No.2066 and No.2067 leave the same value.
If Velocity loop high-speed proportional processing function is used, No.2017#7=0 -> 1.
4. The setting for Feed-forward control with Learning HRV2 control
If you use the coefficient (No.2068) for Feed-forward control with Learning HRV2 control on series 16
i,
you should use the coefficient (No.2092) for advanced Feed-forward control on series 30
i.
