  2. FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator

FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 3

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ’05.04.20 N.Sonoda Newly designed Sheet 03
Edit Date Design Description / 064
1. Overview
This manual only describes the special functions and parameters in FANUC Digital AC Servo applied to
Learning control with High-speed Cutting (G05).
• High-speed Cutting (G05) means "Memory operation” by High-speed Cycle Cutting, “DNC operation”
by Personal Computer through HSSB, or “Data Server operation” by High-speed binary operation.
The merit and major specification of Learning control
The Learning control by digital servo software enables high-precision control for the command and the
cutting disturbance given repeatedly at specified intervals. For example, the lead for video cam drum, the
piston or the camshaft for car engine is usually produced with a conventional cam machine using
mechanical way. Learning control enables the customer’s program to replace a conventional cam
machine with a CNC machine.
• Learning period Max. 262 sec.
• Learning memory size 524,288 words (262 sec. as Learning period)
• Pulse distribution period Min. 0.25 msec. (Depending on CNC software version)
• Frequency Band Max. 1,400 Hz (only Learning HRV4 control)
• Profile number Max. 24 profiles
• Learning step number Max. 5 steps
• Learning data 32,000 words/sec. between CNC and Servo
transmission speed All data transmission is 18.4 sec.
Possible to transfer 4 axes at the same time
• Learning data clear speed 128,000 words/sec. (All data clear takes 4.5 sec.)
(Note) Boldface is improved from series 16
i
Table 1-1. Combinations of Servo Software Series and CNC type
For general cutting tools
For High-speed cutting tools
Servo CNC
Servo CNC
Remarks
9080
Series 16-C, 18-C
Series 15-B
9083
9087
Series 16-B, 18-B
Series 16-C, 18-C
HRV
↓
9090
Series 16i-A,
Series 18i-A
FSSB
90A0
Series 16i-A,
Series 18i-A
90A3
90A7
Series 16i-A,
Series 18i-A
HRV2
↓
90B0
Series 16i-A, B
Series 18i-A, B
90B3
90B7
Series 16i-A, B
Series 18i-A, B
HRV3
↓
90D0
Series 30i-A
Series 31i-A
90D3
Series 30i-A
Series 31i-A
HRV4
90E0
Series 30i-A
Series 31i-A
Series 32i-A
90E3
Series 30i-A
Series 31i-A
HRV3
(4-axes
/DSP)
