  2. FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator

FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 54

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ’05.04.20 N.Sonoda Newly designed Sheet 054
Edit Date Design Description / 064
Appendix 1. Notes on the order
1-1. Servo axis Card (i-series)
You must specify the following Servo axis card for 90D3 series.
• 8 axes A02B-0303-H088 (A20B-3300-0450)
1-2. CPU card
CPU card for CNC is required 128MB DRAM type.
B3 (High-speed) A02B-0303-H005
1-3. Servo software series
You need to specify the following digital servo software for Learning Control.
90D3 series A02B-0303-H590#90D3 (A06B-6057-H509#90D3)
1-4. Software options
[Necessary items]
• Learning Control A02B-xxxx-J705 or • Preview Repetitive control A02B-xxxx-J706
• High Speed cycle cutting A02B-xxxx-J832 or • High-speed binary operation A02B-xxxx-J516
• Setting unit IS-C A02B-xxxx-J805
If High-speed binary operation is applied, Date Server or Open CNC is required.
"Handle interrupt function during High-speed cycle cutting" is included J832.
[At the need arises]
• Learning Memory expanded function A02B-xxxx-J976
• High-speed cycle cutting skip function A02B-xxxx-S662
• Retract function during High-speed cycle cutting A02B-xxxx-J663
• High cycle cutting data variable A / B A02B-xxxx-J745 / J746
• Tandem Disturbance Elimination control function A02B-xxxx-S660
• Pole Position Detection function A02B-xxxx-S744
• Macro executor A02B-xxxx-J888
♦ The above “xxxx” is the following value corresponding to each CNC.
30i-A : 0303 31i-A : 0307 31i-A5 : 0306
