FANUC AC Servo Software 90D3 Series, 90E3 Series Learning FUNCTION, Operator Additional Manual Page 57

Additional Manual
Title 90D3 / 90E3
Learning Control Operator’s Manual
Draw No.
A - 63639E - 108
01 ’05.04.20 N.Sonoda Newly designed Sheet 057
Edit Date Design Description / 064
Standard Parameter for Learning Control for Linear motor (2/4)
(Note 1) You need to set the Learning parameter value because of not auto-Loading.
(Note 2) Regarding High-gain parameter setting for the other motor, refer to 5.2 Setting High-gain
parameters.
Motor type Lis6000B2 Lis600A1 Lis900A1
Motor spec. 0412 422 423
Motor ID (92) (125) (126)
Velocity 0.5ms 0.5ms 0.5ms
Remarks Piston Ring
Amplifiler 80Ap 40Ap 40Ap
Pg No.1825 5000 5000 5000
PI No.2003
00001000 00001000 00001000
Interrupt No.2004
00100001 00100001 00100001
High speed No.2005
00000010 00000010 00000010
HS Veloc. No.2017
00000000 00000000 00000000
Learning
No.2019
x1xxxxxx x1xxxxxx x1xxxxxx
Linear No.2010
00000100 00000100 00000100
Compatible No.2227
xxxxx1xx xxxxx1xx xxxxx1xx
PK1 No.2040 6833 720 480
PK2 No.2041 -12667 -5537 -3691
PK3 No.2042 -1603 -763 -763
PK1V No.2043 23 11 16
PK2V No.2044 -623 -731 -1073
PK4V No.2046 -14412 -24708 -24708
PPMAX No.2053 21 21 21
PDDP No.2054 1894 1894 1894
PHYST No.2055 319 319 319
TRQLIM No.2060 7282 6554 7282
POVC1 No.2062 32670 32731 32685
POVC2 No.2063 1222 463 1041
POVCLM No.2065 3626 1373 3089
RTCURR No.2086 1402 862 1293
MGSTCM No.2110 0 0 0
FBND
No.2512
200 150 150
GODMX
No.2526
51515
GODMN
No.2527
000
GCOEF
No.2528
384 64 64
EXGX K2
No.2529
-51 -32 -32
EXGX K3
No.2530
-22300
EXGX K4
No.2531
-21400
EXGX K5
No.2532
-100
EXGX K6
No.2533
13700
