AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 178

Parameter manual

Page of 760

/ 760

2.EXPLANATION OF OPERATION MODES FANUC AC SPINDLE MOTOR αi series B-65280EN/05

- 154 -

NOTE

This parameter is valid with 9D50 Series N (14)

edition or later and 9D70 series D (04) edition or

later.

16i 30i

4516 4516

Excessive positional deviation alarm detection level on spindle synchronous

control

Unit of data : 100 pulses (weight of 4096 pulses/rev)

Valid data range : 0 to 32767

Standard setting : 0

This parameter sets a level for detecting the excessive positional

deviation alarm under spindle synchronous control.

If the positional deviation (position error) exceeds the value set in this

parameter in the spindle synchronous control mode, the excessive

positional deviation alarm under spindle synchronous control (SPM

alarm C9) is detected. When this parameter is set to 0, alarm detection

is disabled.

As an alarm level, set a value greater than the positional deviation

(position error) equivalent to the spindle speed specified in the spindle

synchronous control mode. The positional deviation equivalent to the

spindle speed can be calculated from the following expression:

Positional deviation [pulse]

= Spindle speed [min

-1

] / 60 × 4096 × 100 / PG

where

PG: Position gain on synchronous control (Nos.4065 to 4068)

NOTE

This parameter is valid with 9D50 Series N (14)

edition or later and 9D70 series D (04) edition or

later.
