AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 751

Parameter manual

Page of 760

/ 760

1/6

Design.

Date Ed.

05.08.03

HEET

DRAW. No.

TITLE

G.L i

Revision of spindle software for αi SP,

βi SVSP TYPE C (9D60/C)

B-65280E/05-02

FANUC LTD

Revision of spindle software for αi SP, βi SVSP TYPE C (9D60/C)

1. General

Spindle software for αi SP, βi SVSP TYPE C was revised as follows.

2. Software series, edition and applied amplifier

Software

drawing No.

Software

edition

Amplifier specification Applied PCB

αi SP series

A06B-6116-Hxxx#H560

A20B-2100-0802

A06B-6116-H560 9D60

edition C

(03)

βi SVSP series

A06B-6134-Hxxx#C

A20B-2101-0012+A20B-2902-0672

A20B-2101-0013+A20B-2902-0672

3. Contents of modification

Software

series and

edition

Contents

9D60/C

1) Measurable data at the Graph Window for SERVO GUIDE is added. For details,

please refer to item 4.

2) Following motor model codes are added. As for parameter list of each motor

model, please refer to “FANUC AC SPINDLE MOTOR α

i series/ FANUC AC

SPINDLE MOTOR β

i series PARAMETER MANUAL (B-65280EN/05).

(Motor model) (Model code)

αC1/6000i : 240

αC2/6000i : 241

αC3/6000i : 242

αC6/6000i : 243

αC8/6000i : 244

αC12/6000i : 245

αC15/6000i : 246

3) FS30i /31i /32i is supported.
