B-65280EN/05 FANUC AC SPINDLE MOTOR αi series 2.EXPLANATION OF OPERATION MODES

- 71 -

2.2.12 Calculating the Orientation Time

The time required for orientation differs between the first orientation

(before the one-rotation signal has first been detected) and the second

and subsequent orientations (once the one-rotation signal has been

detected).

(1) Before the one-rotation signal has first been detected(first

orientation)

The time, from the input of an orientation command until

orientation stops, is divided into four periods.

In the following figure, A indicates that the motor in the stop

state starts rotating and is accelerated to the orientation speed. B

indicates that the already rotating motor is decelerated to the

orientation speed.

: Time required to achieve orientation speed Nori [sec]

: Time from the detection of a one-rotation signal (0 to 1 rotation) after Nori is achieved, until the

number of pulses output before the next one-rotation signal has been checked [sec]

: Time from the completion of the checking of the number of pulses until deceleration starts [sec]

: Time from the start of deceleration until orientation is completed [sec]

Motor speed

Time

(a) Normally, t

is measured on the actual machine.

Orientation speed Nori [min

-1

] is calculated from position

gain PG [sec

-1

] and the motor speed limit ratio for

orientation Rori.

Rori60PGNori

(b) t

is the time required for the motor to rotate one to two

turns at orientation speed Nori [min

-1

RoriPG

Nori

602

Nori

601

≤≤

∴

≤≤

is the time required for the motor to rotate zero to one

turns at orientation speed Nori [min

-1

RoriPG

Nori

601

Nori

600

≤≤∴

≤≤
