5.FUNCTION DESCRIPTIONS FANUC BUILT-IN SPINDLE MOTOR Bis series B-65280EN/05

- 604 -

5.4.6 List of Related Parameters

Parameter No.

15i 16i 30i

Description

3015 #0 4015 #0 4015 #0

Whether the spindle orientation function is available (to be set to "1")

(The CNC software option is required.)

3018 #6 4018 #6 4018 #6 High-speed spindle orientation function (to be set to "1")

5609#2 3702#3,#2 3729#0

Whether the stop position external setting-type spindle orientation function

is available

(For 16i, #2: First spindle, #3: Second spindle)

3003 #0 4003#0 4003#0 Spindle orientation type selection (to be reset to "0")

3003#3,#2 4003#3,2 4003#3,#2

Rotation direction for spindle orientation (to be reset to "0, 0" or to be set to

"0, 1")

3017#7 4017#7 4017#7 Short-cut function when spindle orientation from stopped state is specified

3018#5 4018#5 4018#5

Whether the speed command correction function for high-speed spindle

orientation is available

3031 4031 4031

Spindle orientation stop position

(This parameter is invalid for stop position external setting type and

incremental command external setting type.)

3038 4038 4038 Orientation speed upper limit

3042

3043

4042

4043

4042

4043

Velocity proportional gain on orientation

(These parameters are selected with the input signal CTH1A.)

3050

3051

4050

4051

4050

4051

Velocity integral gain on orientation

(These parameters are selected with the input signal CTH1A.)

3056 to 3059 4056 to 4059 4056 to 4059

Gear ratio data between spindle and motor

(These parameters are selected with the input signals CTH1A and

CTH2A.)

3060 to 3063 4060 to 4063 4060 to 4063

Position gain on orientation

(These parameters are selected with the input signals CTH1A and

CTH2A.)

3064 4064 4064 Percentage limit to an acceleration during deceleration

3075 4075 4075 Orientation completion signal detection level

3077 4077 4077 Orientation stop position shift value

3320 to 3223 4320 to 4323 4320 to 4323

Acceleration during motor deceleration

(These parameters are selected with the input signals CTH1A and

CTH2A.)

3326

3330

4326

4330

4326

4330

Acceleration limitation start speed during deceleration

(These parameters are selected with the input signal CTH1A.)

3328 4328 4328 Command multiplier for orientation

NOTE

1 See Section 1.3, "PARAMETERS RELATED TO DETECTORS" in Part IV, for

parameters related to detectors.

2 See Section 4.1, "VELOCITY LOOP GAIN ADJUSTMENT" in Part IV, for velocity

loop proportional/integral gain tuning.

3 When using the high-speed spindle orientation function, set the parameters (bits 3

and 2 or parameter No. 4003) for rotation direction for spindle orientation with the

previous rotation direction (0, 0 or 0, 1).
