AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 516

Parameter manual
1.START-UP FANUC BUILT-IN SPINDLE MOTOR Bis series B-65280EN/05
- 492 -
1.3 PARAMETERS RELATED TO DETECTORS
NOTE
1 Note that the specifications of parameters related
to detectors for the αi series spindle amplifiers
differ from those of parameters for the α series
spindle amplifiers.
2 The sensor used with the Bis series spindle is a
BZi sensor or CZi sensor.
1.3.1 List of Parameters for Detectors
For this subsection, see Subsection 1.3.1, "List of Parameters for
Detectors", in Part I.
1.3.2 Details of Parameters for Detectors
For this subsection, see Subsection 1.3.2, "Details of Parameters for
Detector", in Part I.
