AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 375

Parameter manual
B-65280EN/05 FANUC AC SPINDLE MOTOR βi series 1.START-UP
- 351 -
1.2 SPINDLE SERIAL INTERFACE
Optional function
1.2.1 Parameters Related to Spindle Serial Output
For this subsection, see Subsection 1.2.1, "Parameters Related to
Spindle Serial Output", in Part I.
1.2.2 Automatic Spindle Parameter Initialization
(1) Parameter list
Parameter No.
(0i)
Description
4019#7 Function for automatically initializing spindle parameters
4133 Spindle motor model code
(2) Procedure for automatic spindle parameter initialization
Perform automatic spindle parameter initialization by following the
procedure below.
<1> Set the model code for the desired motor for automatic parameter
initialization.
Parameter No. (0i)
Description
4133 Model code
NOTE
When using a spindle motor that has no model
code, set model code "300" for automatic
parameter setting, then manually input data
according to the model-by-model parameter list.
<2> Set the relevant parameter to enable automatic spindle parameter
initialization.
Parameter No. (0i)
Description
4019#7 1
NOTE
This bit is reset to its original value after automatic
parameter initialization.
<3> Turn off then turn on again the power to the CNC. The spindle
parameter data set with the model code is automatically
initialized.
<4> According to the detector configuration, set the detector-related
parameters.
