B-65280EN/05 FANUC AC SPINDLE MOTOR αCi series 2.EXPLANATION OF OPERATION MODES

- 471 -

15i 16i 30i

#7 #6 #5 #4 #3 #2 #1 #0

3006 4006 4006

SPDUNT GRUNIT

GRUNIT Sets a gear ratio setting resolution:

0 : 1/100 unit

1 : 1/1000 unit

Select a gear ratio data setting resolution from the following:

(a) Resolution based on motor speed increased by a factor of 100

relative to one spindle rotation

(b) Resolution based on motor speed increased by a factor of 1000

relative to one spindle rotation

Depending on the setting of this parameter, the increment system of

the parameters indicated in the table below changes.

Parameter No.

15i 16i 30i

Description

3056 to 3059 4056 to 4059 4056 to 4059 Spindle-to-motor gear ratio data

NOTE

Usually, use the 1/100 unit (setting "0").

SPDUNT Sets the unit of speed.

Set to 0.

15i 16i 30i

#7 #6 #5 #4 #3 #2 #1 #0

3009 4009 4009

LDTOUT

LDTOUT Whether to output the load detection signal (LDT1A) during

acceleration/deceleration

0 : Does not output the load detection signals during acceleration/

deceleration (standard setting value).

1 : Outputs the load detection signals during acceleration/

deceleration (at all times) when the parameter-set level is

exceeded.

15i 16i 30i

#7 #6 #5 #4 #3 #2 #1 #0

3019 4019 4019

PRLOAD SSTTRQ

SSTTRQ Whether to perform torque clamping when the speed is zero

0 : Performs clamping.

1 : Does not perform clamping.

NOTE

Usually, set this parameter to 1 not to perform

clamping.
