B-65280EN/05 FANUC AC SPINDLE MOTOR αi series 1.START-UP

- 17 -

15i 16i 30i

3056 4056 4056

Gear ratio (HIGH) CTH1A=0, CTH2A=0

3057 4057 4057

Gear ratio (MEDIUM HIGH) CTH1A=0, CTH2A=1

3058 4058 4058

Gear ratio (MEDIUM LOW) CTH1A=1, CTH2A=0

3059 4059 4059

Gear ratio (LOW) CTH1A=1, CTH2A=1

Unit of data : (Motor rotation for one rotation of spindle) / 100

(When parameter No. 4006 #1 (GRUNIT) is 1, motor rotation / 1000)

Valid data range : 0 to 32767

Standard setting : 100

These data are used to set the gear ratio between spindle and spindle

motor.

Example :

When the spindle rotates once, set "250" as the data when the

motor rotates 2.5 times.

A parameter is selected with the CTH1A and CTH2A input signals.

Set the gear or clutch status to correspond to the clutch/gear signal

(CTH1A, CTH2A).

NOTE

When an improper value is set in these parameters,

an unexpected operation can occur. For example,

the spindle can continue rotating without stopping at

the time of orientation. So, be sure to set a proper

gear ratio.

15i 16i 30i

3098 4098 4098

Maximum speed for position feedback signal detection

Unit of data : 1min

-1

(Unit of 10 min

-1

when bit 2 (SPDUNT) of parameter No. 4006

= 1)

Valid data range : 0 to 32767

Standard setting : 0

This parameter sets a maximum spindle speed that enables the

detection of a motor/spindle sensor feedback signal.

When "0" is set in this parameter, up to the maximum motor speed can

be detected.

NOTE

Usually, set “0”.
