AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 743

Parameter manual
B-65280EN/05 APPENDIX G.PARAMETER SPECIFICATION DIFFERENCES BETWEEN THE αi SERIES AND Bis SERIES
- 719 -
Contents
15i 16i 30i
αi series Bis series
3292 4292 4292 Velocity at which the current loop integral gain is zero Unused (Set to 0.)
3293 4293 4293
Filter time constant for processing saturation related to the
voltage command
Unused (Set to 0.)
3294 4294 4294 Current conversion constant Unused (Set to 0.)
3295 4295 4295 Secondary current coefficient Unused (Set to 0.)
3296 4296 4296
Criterion level for saturation related to the voltage
command/PWM command clamp value
Unused (Set to 0.)
3297 4297 4297 Slip constant Unused (Set to 0.)
3298 4298 4298
Slip compensation coefficient for a high-speed zone/slip
compensation coefficient at deceleration
Unused (Set to 0.)
3299 4299 4299 PWM command clamp value at deceleration Unused (Set to 0.)
3300 4300 4300 Motor leakage constant Unused (Set to 0.)
3301 4301 4301
Regular-time voltage compensation coefficient for
high-speed zone/regular-time motor voltage coefficient
Unused (Set to 0.)
3302 4302 4302
Acceleration-time voltage compensation coefficient for
high-speed zone/acceleration-time motor voltage coefficient
Unused (Set to 0.)
3303 4303 4303
Time constant for changing the torque (TCMD filter time
constant)
Unused (Set to 0.)
3304 4304 4304
Compensation coefficient between the specification and true
base/maximum torque curve compensation coefficient
Unused (Set to 0.)
3305 4305 4305 Secondary current coefficient for rigid tapping Unused (Set to 0.)
3306 4306 4306
Current loop proportional gain speed coefficient/current
phase delay compensation coefficient
Unused (Set to 0.)
3307 4307 4307
Regenerative power limit for high-speed zone/regenerative
power limit
Unused (Set to 0.)
3308 4308 4308
Deceleration-time excitation current change time
constant/excitation current change time constant
Unused (Set to 0.)
3309 4309 4309 Motor model code Unused (Set to 0.)
3310 4310 4310 Motor overheat detect level (2-word) Unused (Set to 0.)
3324 4324 4324 Motor acceleration at deceleration time (High) Unused (Set to 0.)
3325 4325 4325 Motor acceleration at deceleration time (Low) Unused (Set to 0.)
3327 4327 4327 Acceleration limitation start speed at deceleration time (High) Unused (Set to 0.)
3329 4329 4329
Command multiplication for spindle orientation by position
coder
Unused (Set to 0.)
3331 4331 4331 Acceleration limitation start speed at deceleration time (Low) Unused (Set to 0.)
3335 4335 4335 Number of motor sensor arbitrary teeth Unused (Set to 0.)
3347 4347 4347 Master-slave speed difference state signal output setting Unused (Set to 0.)
3348 4348 4348 Current overload alarm detection level Unused (Set to 0.)
3349 4349 4349 Temperature monitoring time constant Unused (Set to 0.)
3350 4350 4350 Current overload alarm detection level Unused (Set to 0.)
3353#1 4353#1 4353#1 Velocity feedback signal setting in torque tandem operation Unused (Set to 0.)
3353#2 4353#2 4353#2
Relationship of master/slave motor rotation directions in
torque tandem operation
Unused (Set to 0.)
3360 4360 4360 Preload value Unused (Set to 0.)
3365 4365 4365 Load meter compensation 1 Unused (Set to 0.)
3366 4366 4366 Load meter compensation 2 Unused (Set to 0.)
3367 4367 4367 Load meter compensation 3 Unused (Set to 0.)
3373#1 4373#1 4373#1 Setting of the peak hold function for load meter output Unused (Set to 0.)
3376 4376 4376 Load meter compensation 1 Unused (Set to 0.)
3377 4377 4377 Load meter compensation 2 Unused (Set to 0.)
3378 4378 4378 Load meter compensation 3 Unused (Set to 0.)
3379 4379 4379 Load meter compensation 1 Unused (Set to 0.)
3380 4380 4380 Load meter compensation 2 Unused (Set to 0.)
3381 4381 4381 Load meter compensation 3 Unused (Set to 0.)
3398#3 4398#3 4398#3 Whether to use the twin drive function Unused (Set to 0.)
3398#6 4398#6 4398#6
Whether to detect a speed polarity error (SPM alarm d0) in
torque tandem operation
Unused (Set to 0.)
3443 4443 4443 Feed-forward coefficient of velocity loop Unused (Set to 0.)
3467#2 4467#2 4467#2 Setting of the detection lower limit of the one-rotation signal Unused (Set to 0.)
