5.FUNCTION DESCRIPTIONS FANUC AC SPINDLE MOTOR αi series B-65280EN/05

- 290 -

5.6 SPINDLE FINE ACC./DEC. (FAD) FUNCTION

5.6.1 Overview

The spindle fine Acc./Dec. (FAD) function realizes smooth

acceleration/deceleration during rigid tapping and Cs contouring

control by performing acceleration/deceleration processing with

spindle software. It can reduce mechanical shocks that may

accompany acceleration/deceleration.

NOTE

1 This function is usable in a combination of the αi

spindle amplifier and the FANUC Series

16i/18i/21i-MODEL B CNC.

2 This function cannot be used with the FANUC Series

15i MODEL B.

3 This function cannot be used with the FANUC Series

30i /31i /32i.

4 This function cannot be used together with the

spindle EGB function.

5.6.2 Series and Editions of Applicable Spindle Software

Spindle software

Series Edition Remark

Series 9D50 E(05) and subsequent editions

CNC software

Series Edition Remark

Series B0H1 M(13) and subsequent editions

For the FANUC Series 16

i/160i/160is-MB

Series BDH1 M(13) and subsequent editions

For the FANUC Series 18

i/180i/180is-MB

Series BDH5 C(03) and subsequent editions

For the FANUC Series 18

i/180i/180is-MB5

Series DDH1 M(13) and subsequent editions

For the FANUC Series 21

i/210i/210is-MB

Series B1H1 M(13) and subsequent editions

For the FANUC Series 16

i/160i/160is-TB

Series BEH1 M(13) and subsequent editions

For the FANUC Series 18

i/180i/180is-TB

Series DEH1 M(13) and subsequent editions

For the FANUC Series 21

i/210i/210is-TB
