B-65280EN/05 FANUC BUILT-IN SPINDLE MOTOR Bis series 5.FUNCTION DESCRIPTIONS

- 599 -

5.3.4 I/O Signals(CNC↔PMC)

(1) Address list of input signals (PMC→CNC)

15i 16i 30i

#7 #6 #5 #4 #3 #2 #1 #0

1st- G227 G070 G070

ORCMA CTH1A CTH2A

2nd- G235 G074 G074

ORCMB CTH1B CTH2B

1st- G229 G072 G072

INCMDA NRROA ROTAA INDXA

2nd- G237 G076 G076

INCMDB

NRROB ROTAB INDXB

1st- G230 G078 G078

SHA07 SHA06 SHA05 SHA04 SHA03 SHA02 SHA01 SHA00

2nd- G238 G080 G080

SHB07 SHB06 SHB05 SHB04 SHB03 SHB02 SHB01 SHB00

1st- G231 G079 G079

SHA11 SHA10 SHA09 SHA08

2nd- G239 G081 G081

SHB11 SHB10 SHB09 SHB08

(2) Details of input signals (PMC→CNC)

For this item, see Item (2), "Details of input signals (PMC→CNC)", in

Subsection 5.3.4 of Part I.

(3) Address list of output signals (CNC→PMC)

15i 16i 30i

#7 #6 #5 #4 #3 #2 #1 #0

1st- F229 F045 F045

ORARA

2nd- F245 F049 F049

ORARB

1st- F221 F047 F047

INCSTA

2nd- F247 F051 F051

INCSTB

(4) Details of output signals (CNC→PMC)

For this item, see Item (4), "Details of output signals (CNC→PMC)",

in Subsection 5.3.4 of Part I.

5.3.5 Examples of Sequences

For this subsection, see Subsection 5.3.5, "Examples of Sequences", in

Part I.
