B-65280EN/05 FANUC AC SPINDLE MOTOR αCi series 1.START-UP
- 399 -
1.2 SPINDLE SERIAL INTERFACE
Optional function
1.2.1 Parameters Related to Spindle Serial Output
For this subsection, see Subsection 1.2.1, "Parameters Related to
Spindle Serial Output", in Part I.
1.2.2 Automatic Spindle Parameter Initialization
(1) Parameter list
Parameter No.
15i 16i 30i
Description
5607#0 4019#7 4019#7
Function for automatically initializing spindle
parameters
3133 4133 4133 Spindle motor model code
(2) Procedure for automatic spindle parameter initialization
Perform automatic spindle parameter initialization by following the
procedure below.
<1> Set the model code for the desired motor for automatic parameter
initialization.
Parameter No.
15i 16i 30i
Description
3133 4133 4133 Model code
NOTE
When using a spindle motor that has no model
code, set model code "240" for automatic
parameter setting, then manually input data
according to the model-by-model parameter list.
<2> Set the relevant parameter to 1 to enable automatic spindle
parameter initialization.
Parameter No.
15i 16i 30i
Description
4019#7 4019#7 1
5607#0 0
NOTE
This bit is reset to its original value after
automatic parameter initialization.
<3> Turn the CNC off, then on again. Then, the spindle parameters
specified with a model code are automatically initialized.
