AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 183

Parameter manual
B-65280EN/05 FANUC AC SPINDLE MOTOR αi series 2.EXPLANATION OF OPERATION MODES
- 159 -
(1) Input signals (PMC → CNC)
(a) Series 16i
#7 #6 #5 #4 #3 #2 #1 #0
Common to all axes G027
*SSTP2
(*1)
*SSTP1
(*1)
SWS2
(*1)
SWS1
(*1)
Common to all axes G028 GR2 GR1
Common to all axes G029 *SSTP SOR SAR
Common to all axes G030 SOV7 SOV6 SOV5 SOV4 SOV3 SOV2 SOV1 SOV0
1st- G032 R08I R07I R06I R05I R04I R03I R02I R01I
2nd- G034 R08I2 R07I2 R06I2 R05I2 R04I2 R03I2 R02I2 R01I2
1st- G033 SIND SSIN SGN R12I R11I R10I R09I
2nd- G035 SIND2 SSIN2 SGN2 R12I2 R11I2 R10I2 R09I2
NOTE
*1 These signals are valid in multi-spindle control.
(b) Series 30i
#7 #6 #5 #4 #3 #2 #1 #0
Common to all axes G027
*SSTP2
(*1)
*SSTP1
(*1)
SWS2
(*1)
SWS1
(*1)
Common to all axes G028 GR2 GR1
Common to all axes G029 *SSTP SOR SAR
Common to all axes G030 SOV7 SOV6 SOV5 SOV4 SOV3 SOV2 SOV1 SOV0
1st- G032 R08I R07I R06I R05I R04I R03I R02I R01I
2nd- G034 R08I2 R07I2 R06I2 R05I2 R04I2 R03I2 R02I2 R01I2
1st- G033 SIND SSIN SGN R12I R11I R10I R09I
2nd- G035 SIND2 SSIN2 SGN2 R12I2 R11I2 R10I2 R09I2
NOTE
*1 These signals are valid in multi-spindle control.
