AC Spindle Motor Alpha i / Beta i Series Parameter manual Page 575

Parameter manual
B-65280EN/05 FANUC BUILT-IN SPINDLE MOTOR Bis series 2.EXPLANATION OF OPERATION MODES
- 551 -
15i 16i 30i
3021 4021 4021
Maximum speed on Cs contouring control mode
Unit of data : 1min
-1
Valid data range : 0 to 32767
Standard setting : 100
This parameter specifies the maximum speed of a spindle operating on
Cs contouring control mode.
When 0 is specified as the parameter for the feedrate for reference
position return on Cs contouring control mode (parameter No. 4074),
reference position return is performed at the speed specified as the
maximum speed in this parameter.
15i 16i 30i
3036 4036 -
Feed-forward coefficient
Unit of data : 1%
Valid data range : 0 to 100
Standard setting : 0
Set the feed-forward coefficient when feed-forward control is
executed on Cs contouring control.
15i 16i
30
3037 4037 4037
Velocity loop feed-forward coefficient
Unit of data :
Valid data range : 0 to 32767
Standard setting : 0
Set a velocity loop feed-forward coefficient when feed-forward
control is executed on Cs contouring control. Use the following
expression to determine a value to be set:
[spindle inertia + rotor inertia](kg⋅m
2
)
Setting = 214466
×
Maximum motor torque (N
⋅m)
15i 16i 30i
3046 4046 4046
Velocity loop proportional gain on Cs contouring control (HIGH) CTH1A=0
3047 4047 4047
Velocity loop proportional gain on Cs contouring control (LOW) CTH1A=1
Unit of data :
Valid data range : 0 to 32767
Standard setting : 30
These parameters specify the proportional gains of the velocity loop
on Cs contouring control mode.
When the input signal CTH1A = 0, (HIGH) is selected. When the
input signal CTH1A = 1, (LOW) is selected.
