5.FUNCTION DESCRIPTIONS FANUC AC SPINDLE MOTOR αi series B-65280EN/05
- 242 -
5.2.8 List of Related Parameters
Parameter No.
15i 16i 30i
Description
5607#0 4019#7 4019#7 Parameter automatic setting function (MAIN)
3133 4133 4133 Motor model code (MAIN)
5607#0 4195#7 4195#7 Parameter automatic setting function (SUB)
3309 4309 4309 Motor model code (SUB)
3014#0 4014#0 4014#0
Whether the spindle switching function is available (to be set to
"1")
3014#2 4014#2 4014#2
Function of checking the both magnetic contactor contacts for
main spindle and sub-spindle motors in spindle switching
3013
#6 to #2
4013
#6 to #2
4013
#6 to #2
Current dead-band data (MAIN)
3024 4024 4024 Speed zero detecting level (MAIN)
3110 4110 4110 Current conversion constant (MAIN/high-speed characteristic)
3146 4146 4146 Current conversion constant (MAIN/low-speed characteristic)
3189
#6 to #2
4189
#6 to #2
4189
#6 to #2
Current dead-band data (SUB)
3199 4199 4199 Zero-speed detection level (SUB)
3264 4264 4264 Current conversion constant (SUB/high-speed characteristic)
3294 4294 4294 Current conversion constant (SUB/low-speed characteristic)
NOTE
In the FS15i, the parameter automatic setting
function is common to the main and sub-spindle
motors.
5.2.9 Details of Related Parameters
15
i 16i 30i
#7 #6 #5 #4 #3 #2 #1 #0
3014 4014 4014
AXSLCT AXISSL
AXISSL Whether the spindle switching control function is available
0: No spindle switching function is available.
1: The spindle switching function is available (to be set to "1").
AXSLCT Function of checking the contents of both the main spindle and
sub-spindle motor magnetic contactor contacts in spindle switching
0: The check is based on the power line status signal (MCFN)
1: The check is made on the contacts (MCFN and MFNHG) of both
the main and sub-spindle motor magnetic contactors.
