B-65280EN/05 FANUC BUILT-IN SPINDLE MOTOR Bis series 1.START-UP

- 507 -

1.5.5 Related Parameters

(1) Parameters related to magnetic pole detection

15i 16i 30i

#7 #6 #5 #4 #3 #2 #1 #0

3007 4007 4007

EPFSIG

EPFSIG Selects a magnetic pole detection start signal.

0 : Uses SFR or SRV as a magnetic pole detection start signal.

1 : Uses EPFSTR as a magnetic pole detection start signal.

Set this parameter to select a desired start signal.

This parameter is valid in the automatic mode or direct current

activation mode.

15i 16i 30i

3083 4083 4083

Current ratio/motor stop confirmation time in magnetic pole detection operation

The upper three digits (ten thousands, thousands, and hundreds)

indicate a current ratio in magnetic pole detection, and the lower two

digits (tens and ones) indicate a motor stop confirmation time.

Current ratio in magnetic pole detection (upper three digits)

Unit of data : 1%

Valid data range : 0 to 99

Standard setting value : Depends on the motor model.

Set the magnitude of a current command value in magnetic pole

detection operation as a ratio to the maximum current value.

This parameter is valid in the automatic mode or direct current

activation mode.

Motor stop confirmation time (lower two digits)

Unit of data : 0.1sec

Valid data range : 0 to 99

Standard setting value : Depends on the motor model.

Set a period of time for confirming the stop of the motor in the direct

current activation mode.

This parameter is valid in the direct current activation mode.

Usually, this parameter need not be adjusted.

NOTE

If magnetic pole detection position precision is

insufficient for a cause such as friction, the motor

output torque may decrease. In such a case, this

parameter needs to be adjusted.
