B-65280EN/05 FANUC AC SPINDLE MOTOR αi series 5.FUNCTION DESCRIPTIONS

- 247 -

5.3 INCRMENTAL COMMAND TYPE SPINDLE ORIENTATION

(SPINDLE ROTATION SPEED CONTROL)

Optional function

5.3.1 Overview

Incremental command type spindle orientation is a function that

expands the spindle orientation in which a stop position is specified

externally using a position coder.

This function is intended to move the spindle from the position where

it was when a spindle orientation command was input to a position

specified incrementally. It positions the spindle as follows:

The spindle rotates from the position where it was when a spindle

orientation command was input through an incremental angle

specified from the PMC via the CNC. When the spindle orientation is

completed, a completion signal is sent to the PMC via the CNC.

Using the function enables:

(i) Spindle motor-based turret indexing

(ii) Spindle rotation speed control if a command multiplier value

(parameter-specified value) is set to "4096"

NOTE

1 Using this function requires the spindle orientation

CNC software option.

2 Up to about 120 revolutions can be specified as the

maximum allowable spindle speed.

5.3.2 Series and Editions of Applicable Spindle Software

Spindle software

Series Edition Usable CNC

Series 9D50

Edition A(01) and

subsequent editions

FS16i / FS18i / FS21i / FS0i / FS15i

Series 9D70

Edition A(01) and

subsequent editions

FS30i / FS31i / FS32i
