5.FUNCTION DESCRIPTIONS FANUC AC SPINDLE MOTOR αi series B-65280EN/05

- 288 -

5.5.7 Details of Related Parameters

#7 #6 #5 #4 #3 #2 #1 #0

3702

OR2 OR1

OR1 The stop position external setting-type spindle orientation function

(for the first spindle) is:

0 : Disabled

1 : Enabled

Set to “1”.

OR2 The stop position external setting-type spindle orientation function

(for the second spindle) is:

0 : Disabled

1 : Enabled

Set to “1”.

#7 #6 #5 #4 #3 #2 #1 #0

3729

ORT

The stop position external setting-type spindle orientation function is:

0 : Disabled

1 : Enabled

Set to “1”.

i 30i

#7 #6 #5 #4 #3 #2 #1 #0

4014 4014

SYCORI

SYCORI : The synchronous orientation function is:

0 : Disabled

1 : Enabled

Set to "1" for both the spindles.

i 30i

4075 4075

Orientation completion signal detection level

Unit of data : 1 pulse unit (360 degrees/4096)

Valid data range : 0 to 100

Standard setting value : 10

This parameter is used to specify the synchronous orientation

completion pulse width. When the synchronous orientation command

is issued, the synchronous orientation completion signal (FSPPH)

becomes "1" if the spindle stop position is within the setting data

range.

Specify the same value for both the spindles.

This parameter is used also for regular orientation.
