Alpha Series AC Servo Amplifier Descriptions Page 151

Descriptions

Page of 699

/ 699

B–65162E/03

6. HEAT DISSIPATION

131

Table.6.1.2 (c) SVM3 (3–AXES)

Motor used

Total heat

Remaining heat in cabinet

Name

Ordering

number

L axis M axis N axis

Total

heat

dissipa-

tion

Natural

ventilation

Forced air

cooling

(Note)

SVM3–12/12/12

A06B–6079–H301

A06B–6096–H301

α2/3000 α2/3000 α2/3000 79W – –

SVM3–12/12/20

A06B–6079–H302

A06B–6096–H302

α2/3000 α2/3000 αC12/2000 93W – –

SVM3–12/20/20

A06B–6079–H303

A06B–6096–H303

α2/3000 αC12/2000 αC12/2000 106W – –

SVM3–12/20/20

A06B–6079–H304

A06B–6096–H304

αC12/2000 αC12/2000 αC12/2000 120W – –

SVM3

–

20/20/20

A06B–6079–H305

α2/3000 α2/3000 α6/2000 89W 58W (54W)

SVM3

–

20/20/20

A06B–6096–H305

α2/3000 α2/3000 αC22/1500 122W 71W (65W)

SVM3

–

12/20/40

A06B–6079–H306

α2/3000 αC12/2000 α6/2000 102W 62W (57W)

SVM3

–

12/20/40

A06B–6096–H306

α2/3000 αC12/2000 αC22/1500 136W 77W (69W)

SVM3

–

20/20/40

A06B–6079–H307

AB H

αC12/2000 αC12/2000 α6/2000 116W 68W (62W)

SVM3

–

20/20/40

A06B–6096–H307

αC12/2000 αC12/2000 αC22/1500 150W 82W (74W)

NOTE

A vaule enclosed by parentheses indicates the remaining heat when the module is forcibly

air–cooled with an air flow of 2m/s or more.
