Alpha Series AC Servo Amplifier Descriptions Page 492

Descriptions

Page of 699

/ 699

11. OPTION RELATED TO SPINDLE

B–65162E/03

472

Parameter No.

Description

FS0

M/T/TT Description

FS16

M/T

FS15

M/T

First

spindle

Description

FS16

M/T

FS15

M/T

Second

spindle

Position gain

(M series)

0615

0669

0670

0671

(T series)

0406

0407 to

0410

3065 to

3068

5280

5281 to

5284

Tapping axis position gain at rigid tapping time

6565 to

6568

6705 to

6708

3065 to

3068

4065 to

4068

Spindle position gain at rigid tapping time (to be selected by

CTH1A and CTH2A)

Setting related to acceleration/deceleration time constants

0037#6 (M series) ––– –––

Selection of acceleration/deceleration time constant non–

stage switching. (To be set to 1)

0254 (M series) 5605#1 –––

Acceleration/deceleration type setting

(When set to 1: Linear acceleration/deceleration)

(M series)

0077#1

0613

0692

0693

(T series)

0415 to

0418

5605#2

5751

5760

5762

5764

5261

5262

5263

5264

Acceleration/deceleration time constant

(M series)

0077#1

0617

0694

0695

(T series)

0423 to

0426

5605#2

5757

5758

5759

5241

5242

5243

5244

Maximum spindle speed at rigid tapping time

0063#4 ––– 5200#4 Selection of an override at extraction time

0258 (M series)

0254 (T series)

––– 5211 Override value at extraction time

(M series)

0035#1

0400 to

0402

(T series)

0029#3

0419 to

0422

–––

5201#2

5271 to

5274

Acceleration/deceleration time constant at extraction time

Setting of velocity loop gain and motor voltage

6544

6545

6684

6685

3044

3045

4044

4045

Velocity loop proportional gain at rigid tapping time (to be se-

lected by CTH1A)

6552

6553

6692

6693

3052

3053

4052

4053

Velocity loop integral gain at rigid tapping time (to be selected

by CTH1A)

6585 6725 3085 4085 Setting of motor voltage at rigid tapping time

6901 6941 3281 4137

Setting of motor voltage at rigid tapping time (for low–speed

characteristics) (only for the α series)

In–position width, positional deviation limit

(M series)

0618

(T series)

0400

1827 5300 Tapping axis in–position width
